0513-88577698序號Number | 技術(shù)參數(shù)Specifications | 單位Unit | 型號model | ||
YW32-160 | |||||
1 | 公稱力Rated pressure | KN | 1600 | ||
2 | 頂出力Knock-out pressure | KN | 280 | ||
3 | 液體最大壓力Max.hydraulic pressure | Mpa | 25 | ||
4 | 滑塊最大行程Stock of slide | mm | 600 | ||
5 | 頂出活塞最大行程Stock of Knock-out cylinder | mm | 200 | ||
6 | 滑塊下平面至工作臺面最大距離Distance betweendown-flat of slide and worktable | mm | 1050 | ||
7 | 滑塊行程速度Speed of slide | 空載下行Empty descending | mm/s | 120 | |
工作Pressing | mm/s | 8~12 | |||
回程return | mm/s | 80 | |||
8 | 工作臺面有效尺寸worktable of dimensions | 左右L-R | mm | 780 | |
前后F-B | mm | 640 | |||
9 | 機器外形尺寸Overall dimensions of machine | 左右L-R | mm | 1100 | |
前后F-B | mm | 640 | |||
地面以上高h(yuǎn)eight above ground | mm | 3250 | |||
10 | 電機功率Motor power | KW | 11 | ||
11 | 重量Weight | KG | 6000 |
